P3.91 P4.81 P6.25 500mm×500mm 500mm×1000mm LED Interactive Dance Floor Screen

Pixel Pitch: P10.667mm Module size: 320mm×320mm Cabinet size (W×H×T): 640mm×960mm×95mm / 1280mm×960mm×95mm Pixel configuration: DIP Refresh rate: 1200Hz Product material: iron Viewing angle: 120/60 degrees (min 50% brightness) Power consumption (Avg./Max.): 130W / 440W IP Rate: IP65 Panel weight: 25KG

STAGE&EVENTS LED SCREEN SOLUTIONS   How to choose the right LED Screen solution for the Stage Events from  EXCEL , here we have some advices as follows :   1: Small Capacity  Events Business   If it is small stage events Indoor / Outdoor LED Screen business less than 30Square meters as above cases , then EXCEL R Series is available . R Series is a cost-effective type of rental led screen . The connection between modules with cables . R Series , available Pixel Pitch : 2.604 mm , 2.97mm , 3.91mm , 4.81mm     2: Big  Capacity  Events Business   If it is big Capacity stage events Indoor/Outdoor LED Screen business over 50Square meters set-up , then EXCEL Smart Series is available . Smart Series has very robust frame and big locks , it is strong for big screen set-up . While the connections between modules with  hub-board Pin connection . For the 500x500mm Panel , it has a integrated Signal and Power box , very easy for maintenance . Premium Smart Series , available Pixel Pitch : 2.604 mm , 2.97mm , 3.91mm , 4.81mm     For big capacity , we have another New Technology Guide Series as alternative . The feature of this Guide Series is , when 2-5 Power packs got  failure , the screen can still keep working , we call it " Never-Go-Black " LED Screen . Premium Guide Series , available Pixel Pitch : 2.604 mm , 2.97mm , 3.91mm , 4.81mm     What will come together  with the LED Screens   What else you need to get for the business ?   How to confirm the screen Dimensions ◆ If you are running small events business , you can get started with 12 Square meter which can setup one unit of 4x3meters (13x9.8ft ) Screen , also can set-up 2 units of 3x2meters (9.8x6.5ft ) LED Screens . Or get 24 Square meters , so it can set-up 2 units of 4x3meters (13x9.8ft ) LED Screens , especially for outdoor events . ◆ If you are running medium to big events , then at least to get started with 50-100 Square meters or more , so you can do creative designs for the stages .     What Resolution / Pixel pitch should be good ? ◆ If for Outdoor only , P4.81 is good enough . If you want to run both indoor and outdoor , and have enough budget , you can choose to have P3.91 ◆ If for Indoor only , P3.91 is good enough . If  have enough budget and have high end events like conference , then can choose to have P2.6 or P2.97 for high resolution .     What equipments can we connect and to display on the Screen Video Processor     What should we prepare as a buyer before the LED Screen coming ? ◆ The Lan cable (Network CAT6 cable) or Fiber Optical Cable from Video Processor to the LED Screen . If distance from media control room to screen less than 100 meters , then use Lan Cable . If distance over 100 meters , recommend to use Fiber Optical Cable for better signal transmission  .   ◆ The main power cables from Power distribution box to LED Video wall . ◆ Power distribution box  ◆ Installation Trusses

Pixel Pitch: P7.81-15.6mm / P15.6-15.6mm / P15.6-31.25mm / P31.25-31.25mm Cabinet Size: 1000mm×500mm Pixel Configuration: SMD / DIP available Refresh Rate: 1920Hz Brightness: Indoor 6000+ / Outdoor 8000+ Power Consumption (Avg./Max.): 300W / 800W Weight: 15KG

Pixel Pitch: P1.2mm/ P1.5mm/ P1.8mm/ P2mm/ P2.5mm/ P3mm Module Size: 320mm×160mm Pixel Configuration: SMD Refresh Rate: 3840Hz Product Material: Die-casting Aluminum Viewing Angle: 160/160 degrees Power Consumption (Avg./Max.): Energy saving than normal IP Rate: Indoor IP20   EXCEL LED Indoor EM Series High end Indoor Magnetic LED Modules , the rear side of the Module is sealed with housing , better humidity proof and the installation of the led modules will be more flater than normal naked led  modules . For high end level installation of 4K 8K Indoor LED Screen like CCTV Room , TV Station ,Conference Room , Home Theater , indoor stage backdrop etc , this LED Module is the right choice to maintain your good image .

Pixel Pitch: P3mm / P4mm / P5mm / 6mm / P8mm / P10mm Module Size: 320mm×160mm Cabinet Size (W×H×T): 1280mm×960mm×120mm Pixel Configuration: SMD Refresh Rate: 3840Hz Product Material: Magnesium Viewing Angle: 140/140 degrees Power Consumption (Avg./Max.): 300W / 720W IP Rate: Outdoor IP65 Panel Weight: 38.5KG

Pixel Pitch: P2.5 / P3 / P4mm / P5mm / P6mm / P8mm / P10mm Module Size: 320mm×160mm Cabinet Size (W×H×T): 960mm×960mm×120mm Pixel Configuration: SMD Refresh Rate: 1920Hz / 3840Hz Product Material: Magnesium Viewing Angle: 140/140 degree Power Consumption (Avg./Max.): 300W / 800W IP Rate: IP65 Panel Weight: 28KG

Pixel Pitch: P3.076mm / P4 / P5 / P6.667 / 8mm / P10mm Module Size: 320mm×160mm Cabinet Size: 960mm×960mm×120mm(W×H×T) Pixel Configuration: SMD Refresh Rate: 3840Hz Product Material: Magnesium Viewing Angle: 140/140 degree Power Consumption (Avg./Max.): 300W / 800W IP Rate: IP65 Panel Weight: 28KG

Pixel Pitch: P2.6mm / P2.976mm / P3.91mm / P4.81mm Module Size: 250mm×250mm Cabinet Size (W×H×T): 500mm×500mm×88mm Pixel Configuration: SMD Refresh Rate: 3840Hz Product Material: Die-casting Aluminum Viewing Angle: 140/140 degrees Power Consumption (Avg./Max.): 240W / 710W IP Rate: Indoor IP43 / Outdoor IP65 Panel Weight: 7.5KG
